11EM-21041 SFA2104PF AS-2831 PA4984-FN P902309 Excavator Air Filter
Specifiion
| Item | BA-6636AB |
| Type | Excavator Air Filter |
| Part No. | 11EM-21041 |
| SFA2104PF |
| AS-2831 |
| PA4984-FN |
| AF26285K |
| P902309 |
| Applicable Models | HYUDAI R200-5 |
| HYUDAI R210-7 |
| HYUDAI R215-5 |
| HYUDAI R215-7 |
| HYUDAI R225-9 Direct Spray |
| JONYANG JY210E |
| Size A(H:OD:ID) | 490mm : 245/204mm : 135/18mm |
| Size B(H:OD:ID) | 474mm : 128mm : 105/18mm |
| Function | High Voltage |
| Structure | Filter Element And Housing |
Description
Our products are designed with a main filter element and a safety filter element, which can efficiently filter the air entering the engine, promote full combustion of fuel, and ensure stable engine performance. It is also manufactured by a multi-station continuous mold, and a single component is completed at one time, with high dimensional accuracy and strong consistency.
When the engine is working, it needs to suck in a lot of air. If the air is not filtered, the dust suspended in the air is sucked into the cylinder, which will accelerate the wear of the piston group and the cylinder. Larger particles entering between the piston and the cylinder can cause serious "pulling the cylinder", which is especially serious in dry and sandy working environments. The air filter is installed in front of the carburetor or the intake pipe, and plays the role of filtering out dust and sand in the air, so as to ensure that sufficient and clean air enters the cylinder.
This product has two specifiions and models, filter element A and filter element B, A is a large size, B is a small size, so the prices of the two are not the same, different specifiions can be applied to different models and sizes, and the product diagram is only intuitive Display, the specific model size will be shipped according to the size selected by the customer.
Features
1 . Dedied Air Shroud , Pressure Resistance And Corrosion Resistance.
The product uses a wind guide design, which can maximize the filtration efficiency of the gas. The metal mesh is also made of Shanghai Baosteel sheet, which has excellent compression and corrosion resistance. These features extend the life of the filter.
2 . Special PU Glue , Radial Seal For Reliable Performance.
The special PU glue is one-shot injection molding, with good flexibility, high and low temperature resistance, and stable sealing performance. The sealing process adopts radial sealing process, which can provide stable and reliable filtering performance for the filtering system.
3 . Strictly Follow The Original Requirements To Develop Better Products.
We always adhere to the quality policy of "quality assurance, industry expertise", and continue to grow and develop, Hong Kong Baosheng Filter Co., Ltd. has experienced professional designers and quality engineers, and has a complete set of imported professional filter production lines and supporting equipment.
